Cannondale Synapse Carbon 1 2025 - Road Bike













Lightweight
Built to go fast, designed for big days out, and made to keep you comfortable, the Synapse pushes the limits of what an endurance road bike can do. With a sub-1000g carbon frame, wind-cheating tube shapes and impressive stiffness-to-weight, it’s ready for wherever the ride takes you.
Comfortable
Thanks to updates in carbon layup construction, the new Synapse is now 18% more compliant than the previous model. This added comfort makes a noticeable difference on rougher roads, helping riders stay fresher and more in control, mile after mile. Additional features such as the D-shaped design of Synapse’s seatpost and 42mm tyre clearance boosts vertical compliance and improves aerodynamics, reducing muscle fatigue so that you stay fresher on those longer days.
StashPort
The all-new StashPort downtube storage system offers on-the-go practicality without compromising clean lines. Paired with the StashBag, it keeps ride essentials secure and out of sight. Hidden top tube bag mounts, discreet mudguard fittings, and clearance for high-volume tyres make the new Synapse ready for big miles and demanding conditions alike.
Designed around a Hi-MOD carbon frame, this Synapse is incredibly light and finely tuned for comfort, responsiveness and efficiency. Thanks to Proportional Response construction, each frame size is engineered to deliver the same consistent ride feel across the size range, whether you’re a smaller climber or taller power rider.
Key Features:
- Hi-MOD carbon frame with Proportional Response and StashPort storage
- Hi-MOD carbon fork with Delta steerer and internal routing
- Shimano Ultegra Di2 12-speed electronic drivetrain
- Shimano Ultegra R8170 hydraulic disc brakes
- Reserve 42|49 Aero carbon wheels with Vittoria Corsa PRO Control tyres
- Integrated SystemBar R-One cockpit and 4iiii power meter
- Available with 0% APR finance
Cannondale’s StashPort storage system, neatly integrated into the downtube, gives you a practical place to store ride essentials, tools or spares without cluttering the frame or compromising aerodynamics. Fully SmartSense Gen 2 equipped, the bike also includes integrated lights and radar functionality for extra safety and visibility on open roads.
At the front, the Hi-MOD carbon fork with a Delta steerer delivers exceptional stiffness and direct handling, especially noticeable when descending at speed or changing direction under load. Internal cable routing keeps the whole setup sleek and streamlined.
Where the Synapse Carbon 1 really shines is in its drivetrain. The Shimano Ultegra Di2 12-speed groupset delivers fast, wireless shifting with incredible precision and consistency. Whether you're on a club ride, tackling an epic sportive or just climbing out of the saddle, every gear change is seamless. A 4iiii PRECISION 3+ PRO power meter is fitted as standard to the Ultegra chainset, giving you the data you need to train smart and pace perfectly.
Braking is handled by Shimano Ultegra R8170 hydraulic disc brakes, matched with 160mm rotors front and rear for superb stopping control in all weather. These brakes are race-proven, reliable and highly modulated.
The Reserve 42|49 carbon wheelset features a mixed-depth design for aero performance and crosswind stability, built on DT Swiss 350 hubs and laced with Sapim CX-Ray aero spokes for speed and strength. Fitted with Vittoria Corsa PRO Control 32c tyres, the wheels offer superb grip and handling especially useful on unpredictable UK roads or early season races.
The finishing kit keeps performance front and centre. The SystemBar R-One integrated cockpit, co-developed with MomoDesign, improves aero flow while enhancing comfort and responsiveness. A Cannondale C1 Aero carbon seatpost and Fizik Vento Argo R5 saddle ensure all-day support without compromising speed.
For riders who want endurance comfort with pro-level performance and smart integration, the Synapse Carbon 1 is a fast, future-ready road bike built to go long and go fast.
Occasionally, without notice, manufacturers change product design and/or specifications.
Frame | Synapse Hi-MOD Carbon, Proportional Response construction, integrated cable routing, downtube Stashport, 12x142 thru-axle, UDH, BSA 68mm threaded BB, flat mount disc, integrated seat binder, SmartSense Gen 2.0 equipped, fender mounts |
Fork | Synapse Hi-MOD Carbon, integrated crown race, 12x100mm thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/5" Delta steerer, 55mm offset, fender mounts |
Headset | Integrated, 1-1/8" - 1-1/2" |
Stem | Cannondale SystemBar R-One - low drag, full carbon integrated bar/stem, internal routing |
Bars | Cannondale SystemBar R-One - low drag, full carbon integrated bar/stem, internal routing |
Front Brake | Shimano Ultegra R8170, 160/160mm CL800 rotors |
Rear Brake | Shimano Ultegra R8170, 160/160mm CL800 rotors |
Brake Lever | Shimano Ultegra Di2 R8170 hydraulic disc |
Front Mech | Shimano Ultegra Di2 R8150 |
Rear Mech | Shimano Ultegra Di2 R8150 |
Shifters | Shimano Ultegra Di2 R8170, wireless, 12-speed |
Rims | Reserve 42 | 49 Turbulent Aero, 24h, tubeless ready |
Front Hub | (F) DT Swiss 350, 12x100mm centerlock / (R) DT Swiss 350, 12x142mm centerlock |
Rear Hub | (F) DT Swiss 350, 12x100mm centerlock / (R) DT Swiss 350, 12x142mm centerlock |
Spokes | Sapim CX-Ray Aero straight pull |
Front Tyre | Vittoria Corsa PRO Control, 700x32c, tubeless ready |
Rear Tyre | Vittoria Corsa PRO Control, 700x32c, tubeless ready |
Seat Post | Cannondale C1 Aero 27 Carbon, SmartSense compatible, 330mm length, 0mm offset (44-48cm), 15mm offset (51-61cm) |
Saddle | Fizik Vento Argo R5, 140mm |
Chainset | Shimano Ultegra R8100, 50/34, 4iiii PRECISION 3+ PRO Power Meter |
Bottom Bracket | Shimano BSA 68 |
Chain | Shimano Ultegra, 12-speed |
Cassette | Shimano Ultegra R8100, 11-34, 12-speed |
Cannondale Synapse 2025 Size Chart
Size | Height (cm) | Height (Inches) |
44 | 152 - 162 | 5'0" - 5'4" |
48 | 157 - 167 | 5'2" - 5'6" |
51 | 165 - 175 | 5'5" - 5'9" |
54 | 170 - 180 | 5'7" - 5'11" |
56 | 175 - 185 | 5'9" - 6'1" |
58 | 182 - 193 | 6'0" - 6'4" |
61 | 190 - 203 | 6'3" - 6'8" |
Cannondale Synapse 2025 Geometry Chart
Size | 44 | 48 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|---|
Stack | 510 | 530 | 550 | 570 | 590 | 610 | 640 |
Reach | 365 | 371 | 376 | 381 | 387 | 393 | 402 |
Head Tube Length | 96 | 115 | 140 | 160 | 181 | 205 | 236 |
Head Tube Angle | 70.2° | 70.8° | 71.0° | 71.9° | 72.0° | 72.0° | 72.0° |
Bottom Bracket Height | 263 | 263 | 268 | 270 | 270 | 273 | 273 |
Bottom Bracket Drop | 80 | 80 | 75 | 73 | 73 | 70 | 70 |
Trail | 65 | 61 | 60 | 54 | 54 | 54 | 54 |
Fork Rake/Offset | 55 | 55 | 55 | 55 | 55 | 55 | 55 |
Front Centre | 584 | 591 | 602 | 606 | 617 | 630 | 649 |
Chainstay Length | 415 | 415 | 415 | 415 | 415 | 415 | 415 |
Wheelbase | 985 | 993 | 1006 | 1010 | 1021 | 1035 | 1054 |
Top Tube Length (horizontal) | 521 | 533 | 544 | 555 | 567 | 580 | 598 |
Standover Height | 681 | 702 | 723 | 753 | 784 | 810 | 845 |
Seat Tube Length | 400 | 422 | 443 | 480 | 520 | 550 | 590 |
Seat Tube Angle | 73.0° | 73.0° | 73.0° | 73.0° | 73.0° | 73.0° | 73.0° |
All measurements are in mm unless otherwise stated.
The above table shows the standard geometry for the bicycle as shipped, other geometry configurations may be available with certain bikes. Please contact us via Live Chat to find out more.
