Marin Alpine Trail E2 - Nearly New – M 2025 - Electric Mountain Bike
We've increased the travel by 10mm at both ends, now standing at 170mm (f) and 160mm (r), and relocated the pivots to the chainstays to deliver the suspension performance and tunability demanded by the longer travel. Riders have the ability to alter the head tube angle by +/- .75° by repositioning the lower headset cup while the bottom bracket height/chainstay length can be changed by the means of seatstay flip chips.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | All New, Series 4 Alloy Frame, 160mm Multitrac Suspension LT, Adjustable Headset & CS Length/Height, Integrated Battery/Charging Port, 148mm Rear Thru-Axle |
| Fork | Charcoal/Black and Fox 38 Performance Elite, 170mm Travel, 29" , 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender |
| Rear Shock | Fox Float DHX2, Performance Elite, Low Speed Compression and Rebound Adjustment, 205x65mm, Trunnion Upper Mount, 25mmxM8 Lower Mount, S/M Spring Rate = 350lb, L/XL Spring Rate = 450lb |
| Headset | FSA Custom Headset, Adjustable HTA Design |
| Stem | Marin CNC Stem, 35mm Length, 35mm Bar Bore |
| Bars | Marin Trail Bar, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back |
| Front Brake | TRP DH-R EVO 4-Piston Hydraulic Disc Brakes, 203mm 2.3mm Thick Rotor |
| Rear Brake | TRP DH-R EVO 4-Piston Hydraulic Disc Brakes, 203mm 2.3mm Thick Rotor |
| Brake Lever | TRP DH-R EVO Hydraulic Disk Brakes |
| Rear Mech | Shimano XT 12-Speed, SGS |
| Shifters | Shimano SLX 12-Speed, I-Spec EV |
| Speed | 12 |
| Rims | Front: Marin Aluminum Double Wall, 29" Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible; Rear: Marin Aluminum Double Wall, 27.5" Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible |
| Front Hub | Shimano Front Hub, 110x10 Thru Axle, 32H, Centerlock |
| Rear Hub | Shimano FHTC500, 148x12 Thru Axle, Mircospline, 32H, Centerlock |
| Spokes | 14g Black Stainless Steel |
| Front Tyre | Vee Tire Co Attack HPL, E-Control Compound, Front 29x2.5" |
| Rear Tyre | Rear 27.5x2.5" With Cush Core Pro Tire Inserts |
| Seat Post | TranzX, YSP39 1x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm |
| Saddle | Marin Speed Concept |
| Chain | KMC E12S, E-Bike Specific Chain |
| Cassette | Shimano SLX M7100 Cassette, 12-Speed, 10-51T |
| Battery Size (WH) | Bosch PowerTube 750 Wh |
| Motor | Bosch Performance CX, 85Nm |
| User Interface | Bosch BRC3100 Systems Controller |
Typical Bike Size Chart
|
Height
|
Bike Size
|
Road Bike Size
|
Mountain Bike Size *
|
|
4’8” – 5’1”
143 – 155 cm
|
XXS
|
44 cm
|
13” (33 cm)
|
|
5’1” – 5’4”
155 – 163 cm
|
XS
|
48 cm
|
15” (38 cm)
|
|
5’4” – 5’7”
163 – 170 cm
|
S
|
51 cm
|
16” (41 cm)
|
|
5’7” – 5’10”
170 – 178 cm
|
M
|
54 cm
|
18” (46cm)
|
|
5’10” – 6’0”
178 – 183 cm
|
L
|
56 cm
|
19” (48cm)
|
|
6’0” – 6’3”
183 – 191 cm
|
XL
|
58 cm
|
20” (51 cm)
|
|
6’3” – 6’5”
191 – 196 cm
|
XXL
|
60 cm
|
21” (53 cm)
|
|
6’5” – 6’9”
196 – 205 cm
|
XXXL
|
62 cm
|
22” (56 cm)
|
* Mountain bikes are sized differently to road bikes. Typically, they are sized in inches as the first MTBs were produced in the USA. European brands like Lapierre and Haibike like to use centimetres for all their bikes. The measurements of their mountain bikes doesn’t match their road bikes but are like a simple conversion from the inches measurement. This is why we have included cm measurements in brackets for the Mountain bike column.
Read our bike size guide for more information on sizing.
