Specialized Chisel Mountain Bike 2026 - XC Full Suspension MTB
The Specialized Chisel pairs a D’Aluisio Smartweld alloy frame with Ride Dynamics tuned suspension, RockShox Recon 120mm fork, X-Fusion shock and SRAM NX Eagle 12-speed drivetrain. Lightweight and efficient, it’s made for XC speed with control and confidence.
Key Features
- D’Aluisio Smartweld M5 alloy frame, hydroformed, 110mm travel
- RockShox Recon Silver RL fork, 120mm travel
- X-Fusion PRO-02 rear shock, Ride Dynamics tuned, 110mm travel
- SRAM NX Eagle 12-speed drivetrain, wide 11–50T range
- SRAM DB6 4-piston hydraulic disc brakes, 180/160mm rotors
- 29” alloy tubeless-ready wheels with Ground Control/Fast Trak tyres
- TranzX dropper seatpost fitted as standard
- Available with 0% APR finance
The Specialized Chisel has been reimagined as a full suspension XC bike, offering the efficiency and speed of a race bike with the compliance and control needed for modern technical courses. At its heart is a D’Aluisio Smartweld M5 alloy frame, using advanced hydroformed tubing and a one-piece seat tube design to save weight while maintaining stiffness. The result is one of the lightest alloy XC full suspension frames available, offering class-leading efficiency and responsiveness.
Suspension performance is drawn from the World Cup-proven Epic 8 platform, scaled into an alloy package. With 110mm of rear travel via a Ride Dynamics tuned X-Fusion PRO-02 shock and a RockShox Recon Silver RL fork delivering 120mm up front, the Chisel smooths rough terrain without losing the pedal efficiency needed for racing. Flex Stay rear stays reduce weight and simplify maintenance, while still offering traction and control through technical sections.
The drivetrain is SRAM’s NX Eagle 12-speed, giving riders a huge 11–50T range for climbing steep XC tracks and powering along flats. Paired with a stiff NX crankset and durable Powerspline bottom bracket, the shifting is smooth and reliable under pressure. Braking is handled by SRAM DB6 4-piston hydraulic discs with 180mm and 160mm rotors, delivering consistent, confident stopping power.
Wheels are 29” alloy, tubeless-ready with a 27mm inner width, wrapped in Specialized Ground Control (front) and Fast Trak (rear) tyres. This proven XC pairing balances grip, rolling speed and low weight, ideal for race conditions or fast trail laps. A TranzX dropper post adds versatility, making the bike easier to handle on descents and technical trails.
Geometry is progressive yet efficient, with a steep seat tube to position the rider for optimal pedalling, and a slack head angle for stability at speed. Combined with the light weight, this makes the Chisel one of the most efficient pedalling bikes in its category.
The Specialized Chisel is aimed at riders who want a lightweight, race-capable XC full suspension bike without the price tag of carbon. Whether you’re chasing podiums or just chasing your own times, the Chisel offers speed, control and efficiency in an advanced alloy package.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Specialized D''Aluisio Smartweld M5 Alloy, Hydroformed tubes, Progressive XC Geometry, 110mm travel, internal cable routing, BSA BB, 12x148mm spacing, 30.9mm Dropper post compatible |
| Fork | Rockshox Recon Silver RL, 120mm travel, Motion Control damper, 42mm offset, Maxle Stealth, 15x110 thru-axle |
| Rear Shock | X-Fusion PRO-02, 190x40mm, Ride Dynamics Tuned, Rebound adjust, Compression Adjust |
| Stem | Specialized, 3D-forged alloy, 4-bolt, 7-degree rise |
| Bars | Specialized Alloy, 20mm rise, 31.8mm, 760mm wide |
| Front Brake | SRAM DB6, 4-piston caliper, hydraulic disc, 180mm rotor |
| Rear Brake | SRAM DB6, 4-piston caliper, hydraulic disc, 160mm rotor |
| Brake Lever | SRAM DB6 |
| Rear Mech | SRAM NX Eagle, 12-speed |
| Shifters | SRAM SL NX Eagle Trigger |
| Speed | 12 |
| Rims | Specialized Alloy, Tubeless ready, 27mm inner width, disc, 28h |
| Front Hub | Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 32h |
| Rear Hub | Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h |
| Spokes | Stainless, 14g |
| Front Tyre | Specialized Ground Control, Flex Lite Casing, T5/T7 Compound, 29x2.35 |
| Rear Tyre | Specialized Fast Trak, Flex Lite Casing, T5/T7 Compound, 29x2.35 |
| Seat Post | TranzX Dropper, 30.9mm, XS-SM: 100mm, M: 125mm, L-XL: 150mm |
| Saddle | Body Geometry Power Sport, steel rails |
| Chainset | SRAM NX Eagle, Powerspline, 165/170/175mm, 32T |
| Bottom Bracket | SRAM Powerspline |
| Chain | SRAM NX Eagle, 12-speed |
| Cassette | SRAM NX Eagle, 12-speed, 11-50t |
| Pedals | Resin Platform |
| Weight | 13.88 kg |
Specialized Chisel Size Chart
|
Size |
Height (cm) |
Height (inches) |
|
XS |
148 – 158 |
4’10”- 5’2” |
|
S |
158 – 165 |
5’2”- 5’5” |
|
M |
165 - 178 |
5’5”- 5’10” |
|
L |
178 – 185 |
5’10”- 6’1” |
|
XL |
185 – 193 |
6’1”- 6’4” |
|
XXL |
191 - 200 |
6’3”- 6’6” |
What size frame do I need if I am between sizes? - read here
