Trek Madone SLR 7 Gen 8 2025 - Road Bike
Designed for race-day speed and all-day comfort, the Madone SLR 7 Gen 8 features Trek’s lightest aero carbon frame, IsoFlow comfort tech, and a Shimano Ultegra Di2 wireless 12-speed groupset, all set up for aerodynamic advantage.
Key Features:
- 900 Series OCLV Carbon frame with Full System Foil aero shaping and IsoFlow comfort tech
- One-piece carbon fork with tapered steerer and internal brake routing
- Shimano Ultegra Di2 R8170 12-speed wireless drivetrain with 52/36 chainset
- Shimano Ultegra hydraulic disc brakes with 160mm rotors
- Bontrager Aeolus Pro 51 carbon wheels with Pirelli P Zero Race 700x28mm tyres
- Trek Aero RSL integrated cockpit with RSL Aero Bottles and Cages
- Available with 0% APR finance
The Trek Madone SLR 7 Gen 8 is built for serious road cyclists who want a bike that blends race-ready speed, refined comfort and cutting-edge integration. Trek’s premium 900 Series OCLV Carbon frame forms the heart of this performance machine. Engineered with Full System Foil tube shaping, it slices through the air with remarkable efficiency, improving aerodynamics across the entire rider and bike system.
New to this generation is IsoFlow seat tube technology, a feature that increases compliance at the saddle without compromising aerodynamic performance or frame stiffness. It helps reduce fatigue on long rides while maintaining the snappy, direct feel racers demand.
Shifting is handled by Shimano Ultegra Di2 R8170, a 12-speed wireless electronic system known for its precise and consistent performance. You’ll enjoy fast, effortless gear changes even under load, with programmable controls to tailor your shifting to your style. The 52/36 chainset and 11-30 cassette offer the perfect balance of race-ready gearing and climbing capability.
The Shimano Ultegra hydraulic disc brakes paired with CentreLock 160mm rotors deliver confident stopping power in all conditions, while Bontrager Aeolus Pro 51 carbon wheels provide a light yet stable platform for high-speed racing and aggressive cornering. Wrapped in Pirelli P Zero Race 700x28mm tyres, they offer superb grip, low rolling resistance and a supple ride feel.
The Trek Aero RSL integrated bar and stem not only enhances the bike’s aerodynamic profile but also gives you a clean, race-focused cockpit. Added extras like the RSL Aero Bottles and Cages further reduce drag while offering practical hydration storage. With full internal routing, electronic-only compatibility, and a T47 bottom bracket, this bike is engineered for performance and ease of maintenance.
If you want an aero road bike that’s responsive, comfortable, and fully equipped for elite-level riding, the Madone SLR 7 Gen 8 delivers everything you need to take your racing and road cycling to the next level.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | 900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle |
| Fork | Madone Gen 8 one-piece carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100 mm chamfered thru axle |
| Headset | RCS Headset System |
| Stem | Trek Aero RSL Road integrated bar/stem |
| Bars | Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 100 mm stem length |
| Rear Brake | Shimano CL800, CentreLock, 160 mm |
| Brake Lever | Shimano CL800, CentreLock, 160 mm |
| Front Mech | Shimano Ultegra R8150 Di2, braze-on, down swing |
| Rear Mech | Shimano Ultegra R8150 Di2, 34T max cog |
| Shifters | Shimano Ultegra R8170 Di2, 12-speed |
| Speed | 24 |
| Rims | Bontrager Aeolus Pro 51 |
| Front Hub | Bontrager Aeolus Pro 51 |
| Rear Hub | Bontrager Aeolus Pro 51 |
| Front Tyre | Pirelli P Zero Race, 120 tpi, tubeless-compatible, 700x28 mm |
| Rear Tyre | Pirelli P Zero Race, 120 tpi, tubeless-compatible, 700x28 mm |
| Seat Post | Madone aero carbon seat post, 0 mm offset, long length |
| Saddle | Bontrager Aeolus Pro, carbon rails, 145 mm width |
| Chainset | Shimano Ultegra R8100, 52/36, 172.5 mm length |
| Bottom Bracket | Praxis, T47 threaded, internal bearing |
| Chain | Shimano Ultegra/XT M8100, 12-speed |
| Cassette | Shimano Ultegra R8101, 11-30, 12-speed |
Trek Madone Gen 8 Size Chart
| Size | Height cm | Height Feet / Inches | Inseam cm | Inseam Inches |
|---|---|---|---|---|
| XS (47cm) | 143 - 158 cm | 4'8" - 5'2" | 67 - 74 cm | 26" - 29" |
| S (50cm) | 158 - 162 cm | 5'2" - 5'4" | 74 - 76 cm | 29" - 30" |
| M (52-54cm) | 162 - 173 cm | 5'4" - 5'8" | 76 - 81 cm | 30" - 32" |
| ML (56cm) | 173 - 179 cm | 5'8" - 5'10" | 81 - 84 cm | 32" - 33" |
| L (58cm) | 179 - 188 cm | 5'10" - 6'2" | 84 - 88 cm | 33" - 35" |
| XL (60-62cm) | 188 - 213 cm | 6'2" - 7'0" | 88 - 100 cm | 35" - 39" |
What size frame do I need if I am between sizes? - read here
Trek Madone Gen 8 Geometry Chart
| Size | XS | S | M | ML | L | XL |
|---|---|---|---|---|---|---|
| Stack | 507 | 530 | 546 | 562 | 582 | 610 |
| Reach | 370 | 378 | 384 | 389 | 394 | 402 |
| Head Tube Length | 100 | 121 | 136 | 150 | 172 | 201 |
| Head Tube Angle | 71.6° | 72.2° | 72.9° | 73.5° | 73.8° | 73.9° |
| Bottom Bracket Drop | 72 | 72 | 70 | 70 | 68 | 68 |
| Trail | 61 | 62 | 58 | 59 | 57 | 57 |
| Fork Rake/Offset | 50 | 45 | 45 | 40 | 40 | 40 |
| Chainstay Length | 410 | 410 | 410 | 410 | 411 | 412 |
| Wheelbase | 971 | 976 | 981 | 980 | 990 | 1007 |
| Top Tube Length (horizontal) | 517 | 532 | 545 | 557 | 568 | 584 |
| Standover Height | 704 | 734 | 762 | 790 | 820 | 863 |
| Seat Tube Length | 404 | 440 | 476 | 512 | 548 | 609 |
| Seat Tube Angle | 73.8° | 73.8° | 73.6° | 73.4° | 73.4° | 73.4° |
| Saddle rail height min (w/short mast) | 549 | 585 | 621 | 657 | 693 | 754 |
| Saddle rail height max (w/short mast) | 612 | 648 | 684 | 720 | 756 | 817 |
| Saddle rail height min (w/tall mast) | 592 | 628 | 664 | 700 | 736 | 797 |
| Saddle rail height max (w/tall mast) | 654 | 690 | 726 | 762 | 798 | 859 |
All measurements are in mm unless otherwise stated.
The above table shows the standard geometry for the bicycle as shipped, other geometry configurations may be available with certain bikes. Please contact us via Live Chat to find out more.
